GENERAL SPECIFICATION
-
- Cooling Capacity (Min ~ Rated ~ Max) 1.08 ~ 5.31 ~ 5.36 KW 3,685 ~ 18,114 ~ 18,300 Btu/h
- Heating Capacity (Min ~ Rated ~ Max) 1.08 ~ 5.71 ~ 6.10 KW 3,685 ~ 19,480 ~ 20,800 Btu/h
-
- Power Input – Cooling (Min ~ Rated ~ Max) 238 ~ 1,630 ~ 1,900 W
-
- Running Current – Cooling (Min ~ Rated ~ Max) 1.10 ~ 7.50 ~ 9.10 A
-
- EER 3.26 W/W 11.11 (Btu/h)/W
- SEER 14.97
-
- COP 3.46 W/W 11.81 (Btu/h)/W
- Power Supply 1, 220, 50 (Φ/V/Hz)
-
- Available Voltage Range 187 ~ 276 V
- Power Factor – Cooling/Heating 95%/95%
-
- Indoor – Air Flow Rate (Cooling, Max/H/M/L) 19.3/13.5/12/9 m³/min 670.9/476.8/423.8/317.8 CFM
- Indoor – Air Flow Rate (Heating, Max/H/M/L) 20/14/13/9.5 m³/min 706.2/494.4/459/335.5 CFM
-
- Indoor – Sound Pressure Level (Cooling, H/M/L/SL) 44/39/34/31 dB (A)
- Indoor – Sound Pressure Level (Heating, H/M/L) 44/39/34 dB (A)
-
- Indoor – Dimensions (W × H × D) – Net 998 × 345 × 210 mm 39-9/32 × 13-19/32 × 8-9/32 in.
- Indoor – Dimensions (W × H × D) – Shipping 1080 × 422 × 281 mm 42-17/32 × 16-5/8 × 11-1/16 in.
-
- Indoor – Weight (Net) 26.2 (11.9) lb. (kg)
- Indoor – Weight (Shipping) 30.9 (14) lb. (kg)
-
- Indoor – Disconnect Switch 20A
- Indoor – Exterior Color Code Munsell 7.5BG 10/2 (RAL 9016)
-
- Outdoor – Air Flow Rate (Max) 38.0m³/min 1342CFM
- Outdoor – Fan Motor Speed (Cooling, Min ~ Max) 200 ~ 900 rpm
-
- Outdoor – Fan Motor Speed (Heating, Min ~ Max) 200 ~ 900 rpm
- Outdoor – Sound Pressure Level (Cooling, Rated) 54dB (A)
-
- Outdoor – Sound Pressure Level (Heating, Rated) 56dB (A)
- Outdoor – Dimensions (W × H × D) – Net 770 × 545 × 288 mm 30 – 5/16 × 21 – 15/32 × 11 – 11/32 in.
-
- Outdoor – Dimensions (W × H × D) – Shipping 925 × 593 × 393 mm 36 – 13/32 × 23 – 11/32 × 15 – 15/32 in.
- Outdoor – Weight (Net) 75 (34) lb. (kg)
-
- Outdoor – Weight (Shipping) 87.1 (39.5) lb. (kg)
- Outdoor – Max. Fuse Size 20A
-
- Outdoor – Exterior Color Code Munsell 9.54Y 8.34/1.31 (RAL 9001)
- Outdoor – Operation Range (Cooling) 64.4 ~ 118.4 (18 ~ 48) °F (°C) DB
-
- Outdoor – Operation Range (Heating) 23 ~ 64.4 (-5 ~ 18) °F (°C) WB
- Recommened Fuse Amps 20A
-
- Power Supply Cable 3 × 14 (1.5) No. × AWG (mm²)
- Power Supply to Unit Outdoor
-
- Power and Communication Cable 4 × 18 (0.75) No. × AWG (mm²)
- Piping – Size (Liquid) ø1/4 (ø6.35) in. (mm)
-
- Piping – Size (Gas) ø1/2 (ø12.7) in. (mm)
- Piping – Connections Method (Indoor/Outdoor) Flared
-
- Drain Hose Size (O.D, I.D) 27/32, 5/8 (21.5, 16.0) in. (mm)
- Between Indoor & Outdoor – Piping Length (Min/Standard/Max) 11.8/24.6/65.6 (3.6/7.5/20) ft. (m)
-
- Between Indoor & Outdoor – Piping Length (No Charge) 24.6 (7.5) ft. (m)
- Between Indoor & Outdoor – Max. Elevation Difference 32.8 (10) ft. (m)
-
- Between Indoor & Outdoor – Piping Connection Heat Insulation Both liquid and gas pipes
- Refrigerant – Type R410A
-
- Refrigerant – Pre Charge 43.4 (1230) oz. (g)
- Refrigerant – Additional charge 0.22 (20) oz./ft. (g/m)
-
- Refrigerant – Control Capillary
- Refrigerant – Global Warning Potential 2087.5
-
- Refrigerant – t-CO₂ eq 2.568
- Defrost Method Reverse Cycle
-
- Tool Code (Chassis) (Indoor/Outdoor) SK/UL2
- Compressor – Type Twin Rotary
-
- Compressor – Model GAT156MAD
- Compressor – Motor Type BLDC
-
- Compressor – Oil Type/Maker POE (RB68A)/Sun Oil or Jx Nippon
- Compressor – Oil Charge 400cc
-
- Compressor – Manufacturer/Country of Origin LG Electronics/China
- Fan (Indoor) – Type Cross Flow Fan
-
- Fan (Indoor) – Motor Output 30V
- Fan (Outdoor) – Type Propeller Fan
-
- Fan (Outdoor) – Motor Type BLDC
- Fan (Outdoor) – Motor Output 43V
-
- Fan (Outdoor) – Motor Insulation Class E
- Fan (Outdoor) – Motor Enclosure/Ingress Protection TEAO/IPX4
-
- Heat Exchanger – Evaporator (Material, Tube/Fin) Cu/Al
- Heat Exchanger – Evaporator ((ø x Row x Column x FPI x L) x Qty.) (ø7 x 2 x 16 x 20 x 744) x 1
-
- Heat Exchanger – Evaporator (Corrosion Protection) PCM
- Heat Exchanger – Evaporator (Fin Type) Slit
-
- Heat Exchanger – Condenser (Material, Tube/Fin) Cu/Al
- Heat Exchanger – Condenser ((ø x Row x Column x FPI x L) x Qty.) (ø7 x 2 x 24 x 18 x 823) x 1
-
- Heat Exchanger – Condenser (Corrosion Protection) Gold
- Heat Exchanger – Condenser (Fin Type) Louver
